• A-shaped coil design for high heat-transfer efficiency and low static-pressure drop.
Foil-faced insulation included to prevent energy loss within the cabinet.
• Factory-sealed cabinet certified to maintain a 2% or lower air leakage rate at 1.0 inch water column.
• Multi-stage blower with Speed Control to adapt to varying capacity needs.
• Flexible 4-position installation options: Upflow, Horizontal Right, Downflow, Horizontal Left.
• Standard horizontal/vertical condensate drain pans with primary and secondary condensate fittings.
• Field-installable electric heater kits in 5, 7.5, 10, 15, and 20 kW capacities available as add-ons, with multiple electrical entry points.
• Dual front panel, volute, and coil with slide track, TXV with threaded connection for simplified maintenance.
Integrated filter rack with toolless door access for easy filter replacement.
• Copper evaporator connection designed for easy brazing.
• TXV system designed for simple piston replacement.
Long-lasting all-aluminum heat exchanger enhances product durability.
• The R454B refrigerant sensor comes pre-installed, allowing the unit to be compatible with a wider range of room types and applications.
