ComfortStar AHU3 24,000 BTU wall-mounted air handler with front or bottom return.

COMFORTSTAR

24,000 BTU Cooling + Heating - Wall Mounted Ductless Mini Split Air Conditioner Heat Pump - 20 SEER2 Energy-efficient, Voltage 230V

Model No. CH20-24CD-32

SHIPS IN: 24 - 48 HOURS

Works in outdoor temperatures
as low as 5°F.

Specifications:

Type: Wall Mount
Operating Mode: Heating and Cooling
Refrigerant Type: R32
Size (W x D x H):
Indoor - 39.76"x8.66"x12.4"
Outdoor - 36.1"x14.76"x27.56"
Outdoor Ambient Temperature: 5°F
SEER2: 20
Average Coverage Area: Up to 480ft²

View More

$929.25 USD
$1,265.00 USD $929.25 USD
Shipping calculated at checkout.
Found it for less? We’ll do better.
Free Shipping On Orders Over $49
Product Catalog Service Manual Installation Manual Indoor Spare Parts Outdoor Spare Parts Submittal AHRI Certificate  Energy Guide

The ComfortStar CH20-24CD-32 (CH20-32 Series) is a 24,000 BTU ductless mini split heat pump that provides high-efficiency single-zone heating and cooling at 20 SEER2 using eco-friendly R32 refrigerant. Running on 208/230V, its inverter-driven system is designed for spaces up to approximately 480 sq ft. Low-ambient operation supports heating in outdoor temperatures down to -4°F for reliable comfort throughout the year. CH20-32-Series

Key specifications

  • Capacity: 24,000 BTU cooling + heating
  • Efficiency: 20 SEER2
  • Refrigerant: R32
  • Voltage: 208/230V
  • Configuration: Single-zone, wall-mounted
  • Coverage: Up to 480 sq ft
  • Low-temp heating: Operates down to -4°F
  • Model: CH20-24CD-32

🌟 ComfortStar CH20-24CD-32 – 20 SEER2
High-Efficiency Heat Pump. R32 Refrigerant. Wi-Fi Ready.

✅ 24,000 BTU Cooling Capacity
✅ 24,000 BTU Heating Capacity at 47°F
✅ R32 Refrigerant
✅ Rapid Cooling
✅ Turbo Performance Mode
✅ Energy-Saving ECO Mode
✅ Smart Sleep Mode
✅ Louver Position Memory
✅ Filter Cleaning Reminder
✅ Self-Troubleshooting
✅ Refrigerant Leak Detection
✅ Fire-Proven Electrical Box
✅ Wi-Fi Ready
✅ Low-Ambient Temperature Down to -4°F
✅ 208/230V~/60Hz/1P Power Supply
✅ Suitable Area: Up to 480 sq. ft.

📦 System Configuration:
🕹 Remote Control
+ Wall-Mount Indoor Unit + Outdoor Condensing Unit

Products Related to this Item

Refrigerants, fuel gases, electricity and many more hazards are present when working on HVAC system installations and repairs. It is solely up to the individual viewing our products to determine if he/she has the proper safety training and extensive experience required to work on HVAC systems. Our recommendation is that you have a professional install new and repair HVAC Systems.
